INSTRUCTION SET REFERENCE
IDIV—Signed Divide
Description
This instruction divides (signed) the value in the AL, AX, or EAX register by the source operand
and stores the result in the AX, DX:AX, or EDX:EAX registers. The source operand can be a
general-purpose register or a memory location. The action of this instruction depends on the
operand size, as shown in the following table:
Non-integral results are truncated (chopped) towards 0. The sign of the remainder is always the
same as the sign of the dividend. The absolute value of the remainder is always less than the
absolute value of the divisor. Overflow is indicated with the #DE (divide error) exception rather
than with the OF (overflow) flag.
Operation
IF SRC = 0
THEN #DE; (* divide error *)
FI;
IF OpernadSize = 8 (* word/byte operation *)
THEN
temp
<
AX / SRC; (* signed division *)
IF (temp > 7FH) OR (temp < 80H)
(* if a positive result is greater than 7FH or a negative result is less than 80H *)
THEN #DE; (* divide error *) ;
ELSE
AL
<
temp;
AH
<
AX SignedModulus SRC;
FI;
Opcode
Instruction
Description
F6 /7
IDIV r/m8
Signed divide AX (where AH must contain sign-
extension of AL) by r/m byte. (Results: AL=Quotient,
AH=Remainder)
F7 /7
IDIV r/m16
Signed divide DX:AX (where DX must contain sign-
extension of AX) by r/m word. (Results: AX=Quotient,
DX=Remainder)
F7 /7
IDIV r/m32
Signed divide EDX:EAX (where EDX must contain
sign-extension of EAX) by r/m doubleword. (Results:
EAX=Quotient, EDX=Remainder)
Operand SizeDividendDivisorQuotientRemainderQuotient Range
Word/byte
AX
r/m8AL
AH
?
128 to +127
Doubleword/word
DX:AXr/m16AX
DX
?
32,768 to +32,767
Quadword/doublewordEDX:EAXr/m32EAX
EDX
?
2
31
to 2
32
?
1
