GUIDELINES FOR WRITING SIMD FLOATING-POINT EXCEPTION
F.4.3.SIMD Floating-Point Emulation Implementation Example
The sample code listed below may be considered as being part of a user-level floating-point ex-
ception filter for Streaming SIMD Extensions numeric instructions. It is assumed that the filter
function is invoked by a low-level exception handler (reached via interrupt vector 19 when an
unmasked floating-point exception occurs), and that it operates as explained in Section F.4.1.,
Floating-Point Emulation The sample code does the emulation for the add, subtract, multiply,
and divide operations. For this, it uses C code and IA-32 FPU operations (readability, and not
efficiency was the primary goal). Operations corresponding to other Streaming SIMD Exten-
sions numeric instructions have to be emulated, but only place holders for them are included.
The example assumes that the emulation function receives a pointer to a data structure specify-
ing a number of input parameters: the operation that caused the exception, a set of two sub-op-
erands (unpacked, of type float), the rounding mode (the precision is always single), exception
masks (having the same relative bit positions as in the MXCSR but starting from bit 0 in an un-
signed integer), and a flush-to-zero indicator. The output parameters are a floating-point result
(of type float), the cause of the exception (identified by constants not explicitly defined below),
and the exception status flags. The corresponding C definition is:
Table F-15. #U - Numeric Underflow
Instruction
Condition
Masked ResponseUnmasked Response
and Exception Code
ADDPS
SUBPS
MULPS
DIVPS
ADDSS
SUBSS
MULSS
DIVSS
result calculated with
unbounded exponent and
rounded to the destination
precision < smallest single-
precision finite normal value
#UE=1 and #PE=1,
but only if the result is
exact
res = ±0, denormal, or
normal
res = (result calculated with
unbounded exponent and
rounded to the destination
precision) * 2
192
#UE=1
#PE=1 if the result is
inexact
Table F-16. #P - Inexact Result (Precision)
InstructionConditionMasked ResponseUnmasked Response and Exception
Code
ADDPS
SUBPS
MULPS
DIVPS
SQRTPS
CVTPI2PS
CVTPS2PI
CVTTPS2PI
ADDSS
SUBSS
MULSS
DIVSS
SQRTSS
CVTSI2SS
CVTSS2SI
CVTTSS2SI
the result is not
exactly
representable in the
destination format
res = result rounded
to the destination
precision and using
the bounded
exponent, but only if
no unmasked
underflow or overflow
conditions occur (This
exception can occur
in the presence of a
masked underflow or
overflow)
#PE=1
only if no underflow/overflow condition
occurred, or if the corresponding
exceptions are masked:
set #OE if masked overflow and set result
as described above for masked overflow;
set #UE if masked underflow and set
result as described above for masked
underflow;
if neither underflow nor overflow, res = the
result rounded to the destination precision
and using the bounded exponent
set #PE=1
