PROGRAMMING WITH THE STREAMING SIMD EXTENSIONS
The MOVLPS (Move unaligned, low packed, single-precision, floating-point) instruction trans-
fers 64 bits of packed data from memory to the lower two fields of a SIMD floating-point
register and vice versa. The upper two fields are left unchanged.
The MOVMSKPS (Move mask packed, single-precision, floating-point) instruction transfers
the most significant bit of each of the four, packed, single-precision, floating-point numbers to
an IA integer register. This 4-bit value can then be used as a condition to perform branching.
The MOVSS (Move scalar single-precision, floating-point) instruction transfers the least signif-
icant 32 bits from memory to a SIMD floating-point register or vice versa, and between regis-
ters.
9.3.2.Arithmetic Instructions
9.3.2.1.PACKED/SCALAR ADDITION AND SUBTRACTION
The ADDPS (Add packed, single-precision, floating-point) and SUBPS (Subtract packed,
single-precision, floating-point) instructions add or subtract four pairs of packed, single-preci-
sion, floating-point operands.
The ADDSS (Add scalar single-precision, floating-point) and SUBSS (Subtract scalar single-
precision, floating-point) instructions add or subtract the least significant pair of packed, single-
precision, floating-point operands; the upper three fields are passed through from the source
operand.
9.3.2.2.PACKED/SCALAR MULTIPLICATION AND DIVISION
The MULPS (Multiply packed, single-precision, floating-point) instruction multiplies four pairs
of packed, single-precision, floating-point operands.
The MULSS (Multiply scalar single-precision, floating-point) instruction multiplies the least
significant pair of packed, single-precision, floating-point operands; the upper three fields are
passed through from the source operand.
The DIVPS (Divide packed, single-precision, floating-point) instruction divides four pairs of
packed, single-precision, floating-point operands.
The DIVSS (Divide scalar single-precision, floating-point) instruction divides the least signifi-
cant pair of packed, single-precision, floating-point operands; the upper three fields are passed
through from the source operand.
9.3.2.3.PACKED/SCALAR SQUARE ROOT
The SQRTPS (Square root packed, single-precision, floating-point) instruction returns the
square root of the packed four single-precision, floating-point numbers from the source to a
destination register.
